Steel ball automatic cold heading machine
Source：http://www.xuehu9.com Author：冷鐓機(jī) Time：2014/8/17 Click：
The automatic cold heading machine for steel balls is a device used to manufacture bearing rollers, steel ball blanks, and simple deformed workpieces. It adopts the most advanced international technology and is specifically designed for upsetting delicate ball and steel ball blanks. The machine uses cold drawn disc or bar materials and is equipped with floating punch heads. It has a wide range of product specifications and is easy to operate. It is a commonly used equipment in China's bearing industry. The automatic cold heading machine for steel balls is suitable for one-time deformation of workpieces and the function of cutting and making cakes.
加工范圍（Forging size）mm
|
Ø12- Ø14
|
生產(chǎn)能力（Productivity）pcs/min
|
100-120
|
主電機(jī)功率(Motor power)kw
|
15
|
油泵電機(jī)功率(Oil pump motor power)kw
|
0.12
|
電源(Electrical source)v
|
380
|
外型尺寸(Outer size)mm
|
3500*2200*1400
|
重量(Weight)
|
8000
|
